Product Description:
The Square D HJA36060 is a Molded Case Circuit Breaker from the Powerpact family. It features a 3-pole design with a 600V, 60A rating and a 65kA@480V AIC rating. This breaker uses an I-Line Style Plug-In connection and includes Thermal Magnetic protection for reliable performance.
Key Features:
✔ Part Number: HJA36060
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: HJA
✔ Voltage: 600V
✔ Amperage: 60A
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 65kA@480V
✔ Connection: I-Line Style Plug-In
✔ Protection: Thermal Magnetic
✔ Terminal Connection: I-Line, Lug
✔ Frame Size: H
✔ Wire Size: 14 AWG (Min), 3/0 AWG (Max)
✔ Certification: UL, CSA, NEMA, NOM, CE
✔ UPC: 785901600961
✔ GTIN: 00785901600961
✔ Country of Origin: Mexico
