Product Description:
The Eaton HFD3080 is a Molded Case Circuit Breaker from the Series C family. It features a 3-pole design with a 600V, 80A rating and a 65kA@480V AIC rating. This thermal magnetic breaker uses a bolt-on connection and is suitable for various panel types.
Key Features:
✔ Part Number: HFD3080
✔ Manufacturer: Cutler Hammer
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Series C
✔ Type: HFD
✔ Voltage: 600V
✔ Amperage: 80A
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 65kA@480V
✔ Connection: Bolt-On
✔ Protection: Thermal Magnetic
✔ Terminal Connection: Load Side Lug
✔ Frame Size: 225A/F
✔ Wire Size: 14 AWG (Min), 1/0 AWG (Max)
✔ Certification: CSA Certified, IEC Rated, UL Listed
✔ UPC: 786679173282
✔ GTIN: 00786679173282
✔ Country of Origin: Dominican Republic
