Product Description:
The Cutler Hammer CSR2175N is a Molded Case Circuit Breaker from the CSR Series. It features a 2-pole design with a 240V, 175A rating and a 25kA@240V AIC rating. This breaker uses a plug-in connection and offers thermal magnetic protection for reliable circuit safety.
Key Features:
✔ Part Number: CSR2175N
✔ Manufacturer: Cutler Hammer
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: CSR Series
✔ Type: CSR
✔ Voltage: 240V
✔ Amperage: 175A
✔ Phase: 1
✔ Poles: 2
✔ AIC Rating: 25kA@240V
✔ Connection: Plug-In
✔ Functions: LI - Long-Time and Instantaneous
✔ Protection: Thermal Magnetic
✔ UPC: 782113098456
✔ GTIN: 00782113098456
✔ Country of Origin: Dominican Republic
✔ Dimensions: 3.1in (L) x 3.1in (H) x 2in (W)
✔ Weight: 3 lbs
✔ Certification: UL 489
