Siemens BF220A Circuit Breaker | BL Series BLF 120/240 VACV 20A

Product Description:
The Siemens BF220A is a 2-pole Molded Case Circuit Breaker from the BL Series. It operates at 120/240 VAC with a 20A rating and a 10kA@240V AIC rating. This breaker features Bolt-on connections and Thermal Magnetic protection. It is designed for use in Siemens Panelboards and meets multiple safety certifications.

Key Features:
✔ Part Number: BF220A
✔ Manufacturer: Siemens
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: BL Series
✔ Type: BLF
✔ Voltage: 120/240 VAC
✔ Amperage: 20A
✔ Phase: 1
✔ Poles: 2
✔ AIC Rating: 10kA@240V
✔ Connection: Bolt-on
✔ Protection: Thermal Magnetic
✔ Terminal Connection: Lug
✔ Frame Size: 60A/BLHF
✔ Min. Wire Size: 12 AWG (Al), 14 AWG (Cu)
✔ Max. Wire Size: 10 AWG
✔ Breaker Type: Ground Fault Circuit Interrupter (Class A - 5mA)
✔ Certification: CSA Certified, HACR Rated, NOM Certified, UL Listed
